Rental Id: 08-614 Dimension Guide
Yale  ERC080HDN48SQ096
8,000 lb Capacity

Rental ID: 08-614
Make: Yale
Model: ERC080HDN48SQ096
Capacity: 8,000 lbs
Capacity as Equipped: 7,000 lbs @ 24" Load Center
Load Center: 24"
Mast-Overall Lowered Height: 96"
Mast-Maximum Fork Height: 273" Quad
Mast-Overall Raised Height: 322" Approx.
Mast-Free Lift: 66"
Carriage: Maximum Fork Spread Outside Dimension 39.5", Class III
Forks: 48" X 5" X 2" Standard Taper
Attachments: None
Door Clearance Dimension: 101"
Power: 48 Volt
Fuel: 48 Volt Electric
Fuel Capacity: N/A
Transmission: EV100LX Control
Tires: Non Marking Rubber
Dimensions: 48.1" Wide X 96.5" Long (Less Forks) X 96.5" High
Gross Weight: 17,300 lbs Approx
Safety Equipment: OHG, LBR, Backup Alarm, Warning Light, Operating Lights, Seat Belt, Fire Extinguisher, Data Plate, Safety Decals
Accessory: 48 Volt 3 Phase 220/440 Input Charger, (4) Stage Quad Mast
Details: The 8,000# capacity Yale forklift is a heavy duty industrial forklift that can be used in many areas of manufacturing such as the steel industry, canned goods, and rigging. It is also a good general warehouse lift truck used in many distribution centers. This unit from our rental fleet is unique as it is a Quad or 4 stage mast going up to almost 23' of lift. It is an electric type with non marking tires also.

Interstate Heavy Rentals delivers our forklifts to states throughout the Eastern seaboard including Pennsylvania PA, New Jersey NJ, Delaware DE, Maryland MD, New York NY, Vermont VT, New Hampshire, Connecticut CT, Massachusetts MA, Rhode Island RI, Maine ME, Virginia VA, West Virginia WV, Ohio OH, Indiana IN, Kentucky KY, North Carolina NC, South Carolina SC, Tennessee TN, Florida FL, Georgia GA, Mississippi MS, Michigan MI, Alabama AL.

We also deal with some construction lifts and aerials, as well as all kinds of rigger type lifts also known to some as "hi lo's and towmotors". All units are available on short or long term lease, and occasionally we have rental retirements for sale when our company is replenishing our fleet with new equipment. Our standards are very high when it comes to the forklifts we rent to our customers.

All data is as accurate as possible, but not guaranteed against typographical errors.
