Rental Id: 08-616 Dimension Guide
Hyster  E80XL3
8,000 lb Capacity

Rental ID: 08-616
Make: Hyster
Model: E80XL3
Capacity: 8,000 lbs
Capacity as Equipped: 6,600 lbs @ 24" Load Center (With Side Shift Fork Positioner)
Load Center: 24"
Mast-Overall Lowered Height: 92"
Mast-Maximum Fork Height: 194"
Mast-Overall Raised Height: 226" Approx.
Mast-Free Lift: 61"
Carriage: Maximum Fork Spread Outside Dimension 43", 10.5" Minimum with Clamp
Forks: 48" X 5" X 2" Standard Taper
Attachments: Side Shifter, Fork Positioners
Door Clearance Dimension: 97"
Power: 48 Volt 24-85-21 Battery
Fuel: 48 Volt Electric
Fuel Capacity: 48 Volt 1400 AMP 3 Phase 220/440 Input Charger
Transmission: EV100 Control
Tires: Non Marking Solid Rubber
Dimensions: 52" Wide X 99.6" (Less Forks) X 92" High
Gross Weight: 16,800 lbs Approx.
Safety Equipment: OHG, Load Backrest, Warning Light, Operating Lights, Seat Belt, Mirrors, Fire Extinguisher, Data Plate, Safety Decals
Accessory: EE Rated, 48 Volt System, Side Shift Fork Positioner, Clamp Model #100F-FPS=725-05
Details: The 8,000# capacity Hyster forklift is a heavy duty electric forklift that can be used in many areas of manufacturing such as the steel industry, canned goods, rigging, as well as general warehousing and distribution centers.

This unit from our rental fleet is unique as it has an EE rating. An EE rating is when all motors and switches are enclosed to prevent sparks from escaping. This type of truck can be used in some hazardous areas. The unit is also equipped with a side shifting fork positioning clamp, and non marking tires.

Interstate Heavy Rentals delivers our forklifts to states throughout the Eastern seaboard including Pennsylvania PA, New Jersey NJ, Delaware DE, Maryland MD, New York NY, Vermont VT, New Hampshire, Connecticut CT, Massachusetts MA, Rhode Island RI, Maine ME, Virginia VA, West Virginia WV, Ohio OH, Indiana IN, Kentucky KY, North Carolina NC, South Carolina SC, Tennessee TN, Florida FL, Georgia GA, Mississippi MS, Michigan MI, Alabama AL.

We also deal with some construction lifts and aerials, as well as all kinds of rigger type lifts also known to some as "hi lo's and towmotors". All units are available on short or long term lease, and occasionally we have rental retirements for sale when our company is replenishing our fleet with new equipment. Our standards are very high when it comes to the forklifts we rent to our customers.

All data is as accurate as possible, but not guaranteed against typographical errors.
